glass3 broker output class More...

#include <brokerOutput.h>

Inheritance diagram for glass3::brokerOutput:

Collaboration diagram for glass3::brokerOutput:

Public Member Functions
	brokerOutput ()
	brokerOutput constructor More...

	brokerOutput (const std::shared_ptr< json::Object > &config)
	brokerOutput advanced constructor More...

	~brokerOutput ()
	brokerOutput destructor More...

bool	setup (std::shared_ptr< const json::Object > config) override
	brokerOutput configuration function More...

void	clear () override
	brokerOutput clear function More...

void	setStationFileName (const std::string &filename)
	Sets the station file name. More...

const std::string	getStationFileName ()
	Gets the station file name. More...

void	logProducer (const std::string &message)
	the function for producer logging This function is used by the HazDevBroker producer to log messages with neic-glass3's logging system. More...

Public Member Functions inherited from glass3::output::output
	output ()
	output constructor More...

	~output ()
	output destructor More...

void	sendToOutput (std::shared_ptr< json::Object > message) override
	output message sending function More...

bool	start () override
	work thread start function More...

bool	healthCheck () override
	output heath check function More...

void	setSiteListRequestInterval (int delay)
	Function to set the interval for requesting the site list. More...

int	getSiteListRequestInterval ()
	Function to retrieve the interval for requesting the site list. More...

void	setReportInterval (int interval)
	Function to set the interval to generate informational reports. More...

int	getReportInterval ()
	Function to retrieve the interval to generate informational reports. More...

void	setAssociator (glass3::util::iAssociator *associator)
	Function to set the associator interface pointer. More...

glass3::util::iAssociator *	getAssociator ()
	Function to get the associator interface pointer. More...

void	setPubOnExpiration (bool pub)
	Function to set the publish on expiration flag. More...

bool	getPubOnExpiration ()
	Function to retrieve the publish on expiration flag. More...

void	setImmediatePubThreshold (double threshold)
	Function to set the immediate publication threshold. More...

double	getImmediatePubThreshold ()
	Function to retrieve the immediate publication threshold. More...

std::vector< int >	getPubTimes ()
	Function to retrieve the publication times. More...

void	addPubTime (int pubTime)
	Function to add a single publication time to the list. More...

void	clearPubTimes ()
	Function to clear the publication times. More...

bool	addTrackingData (std::shared_ptr< json::Object > data)
	add tracking information to the output tracking cache More...

std::shared_ptr< const json::Object >	getTrackingData (std::string id)
	get tracking information from the output tracking cache by id More...

std::shared_ptr< const json::Object >	getNextTrackingData ()
	get tracking information from the output tracking cache More...

bool	haveTrackingData (std::shared_ptr< json::Object > data)
	check if tracking information is in output tracking cache More...

bool	haveTrackingData (std::string ID)
	check if information is in output tracking cache by id More...

bool	removeTrackingData (std::shared_ptr< const json::Object > data)
	remove tracking information from the output tracking cache More...

bool	removeTrackingData (std::string ID)
	remove tracking information from the output tracking cache by id More...

void	clearTrackingData ()
	clear output tracking cache More...

bool	isDataReady (std::shared_ptr< const json::Object > data)
	check to see if tracking information is ready for output More...

bool	isDataChanged (std::shared_ptr< const json::Object > data)
	check to see if detection data has changed More...

bool	isDataPublished (std::shared_ptr< const json::Object > data, bool ignoreVersion=true)
	check to see if tracking information has been published More...

bool	isDataFinished (std::shared_ptr< const json::Object > data)
	check to see if tracking information is finished More...

void	writeOutput (std::shared_ptr< json::Object > data)
	output writing function More...

glass3::util::WorkState	work () override
	output background work function More...

Public Member Functions inherited from glass3::util::ThreadBaseClass
	ThreadBaseClass ()
	ThreadBaseClass constructor. More...

	ThreadBaseClass (std::string threadName, int sleepTimeMS=100, int numThreads=1, int checkInterval=300)
	An advanced constructor that sets up the ThreadBaseClass with a provided thread name, sleep between work time duration, number of threads, and statsus check interval. More...

	~ThreadBaseClass ()
	ThreadBaseClass destructor. More...

virtual bool	stop ()
	work thread stop function More...

int	getNumThreads ()
	Retrieves the number of work threads. More...

void	setNumThreads (int numThreads)
	Sets the number of work threads. More...

void	setThreadHealth (bool health=true)
	Function to set thread health. More...

void	setSleepTime (int sleepTimeMS)
	Sets the time to sleep between work() calls. More...

int	getSleepTime ()
	Retrieves the time to sleep between work() calls. More...

glass3::util::ThreadState	getWorkThreadsState ()
	Function to get the work threads state. More...

void	setHealthCheckInterval (int interval)
	Function to set work threads health check interval. More...

int	getHealthCheckInterval ()
	Function to retrieve the work threads health check interval. More...

bool	getTerminate ()
	Function to retrieve whether the thread should terminate. More...

const std::string &	getThreadName ()
	Function to retrieve the name of the work threads. More...

std::time_t	getAllLastHealthy (size_t *pThreadId)
	Function to retrieve the oldest time any of the work threads last updated their health status as healthy. More...

Public Member Functions inherited from glass3::util::BaseClass
	BaseClass ()
	BaseClass constructor. More...

virtual	~BaseClass ()
	BaseClass destructor. More...

const std::shared_ptr< const json::Object >	getConfig ()

bool	getSetup ()
	Retrieves the class member boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

const std::string &	getDefaultAgencyId ()
	Function to retrieve the name of the default agency id. More...

void	setDefaultAgencyId (const std::string &id)
	Function to set the name of the default agency id. More...

const std::string &	getDefaultAuthor ()
	Function to retrieve the name of the default author. More...

void	setDefaultAuthor (const std::string &author)
	Function to set the name of the default author. More...

Protected Member Functions
void	sendOutput (const std::string &type, const std::string &id, const std::string &message) override
	output sending function More...

void	sendToOutputTopics (const std::string &message)
	Sends the provided message to each of the output topics. More...

void	sendHeartbeat () override
	Send heartbeats. More...

Protected Member Functions inherited from glass3::output::output
void	checkEventsLoop ()
	output tracking data background work function More...

Protected Member Functions inherited from glass3::util::ThreadBaseClass
void	setWorkThreadsState (glass3::util::ThreadState state)
	Function to set threads state. More...

void	workLoop ()
	ThreadBaseClass work loop function. More...

void	setLastHealthy (std::time_t now)
	Function to set the last time the work thread was healthy. More...

Additional Inherited Members
Static Public Attributes inherited from glass3::output::output
static constexpr int	k_iMinimumPublicationTime = 10
	The minimum time in seconds to publish an event. More...

Protected Attributes inherited from glass3::util::ThreadBaseClass
std::vector< std::thread >	m_WorkThreads
	the std::vector that contains the work std::thread objects More...

std::map< std::thread::id, std::atomic< int > >	m_ThreadHealthMap
	A std::map containing the epoch times as std::atomic<double>> that each work thread was last marked as healthy, identified by the thread id. More...

Protected Attributes inherited from glass3::util::BaseClass
std::shared_ptr< const json::Object >	m_Config
	A shared pointer to the json::Object that holds the configuration. More...

std::atomic< bool >	m_bIsSetup
	the boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

std::string	m_DefaultAgencyID
	A std::string containing the default agency id to use in parsing if one is not provided. More...

std::string	m_DefaultAuthor
	A std::string containing the default author to use in parsing if one is not provided. More...

Detailed Description

glass3 broker output class

The glass3 broker output class is a class encapsulating the broker output logic. The output class handles setting up a hazdevbroker producer, configuring output topic(s) and sending messages from glasscore, to kafka via the hazdevbroker producer

brokerOutput inherits from the glass3::output::output class.

Constructor & Destructor Documentation

glass3::brokerOutput::brokerOutput ( )

brokerOutput constructor

The constructor for the brokerOutput class. Initializes members to default values.

glass3::brokerOutput::brokerOutput ( const std::shared_ptr< json::Object > & config )

explicit

brokerOutput advanced constructor

The advanced constructor for the brokerOutput class. Initializes members to default values. Calls setup to configure the class Starts the work thread

Parameters

config - A json::Object pointer to the configuration to use

glass3::brokerOutput::~brokerOutput ( )

brokerOutput destructor

The destructor for the brokerOutput class. Stops the work thread

Member Function Documentation

void glass3::brokerOutput::clear ( )

overridevirtual

brokerOutput clear function

The clear function for the brokerOutput class. Clears all configuration

Reimplemented from glass3::output::output.

const std::string glass3::brokerOutput::getStationFileName ( )

Gets the station file name.

Returns: Returns A string containing the file name

void glass3::brokerOutput::logProducer ( const std::string & message )

the function for producer logging This function is used by the HazDevBroker producer to log messages with neic-glass3's logging system.

Parameters

message - A string containing the logging message

void glass3::brokerOutput::sendHeartbeat ( )

overrideprotectedvirtual

Send heartbeats.

This function is used to optionally send heartbeat messages to kafka via the hazdev-broker producer.

Reimplemented from glass3::output::output.

void glass3::brokerOutput::sendOutput	(	const std::string &	type,
		const std::string &	id,
		const std::string &	message
	)

overrideprotectedvirtual

output sending function

The function used output detection data

Parameters

type	- A std::string containing the type of the data message
id	- A std::string containing the id of the data message
message	- A std::string containing the data message

Implements glass3::output::output.

void glass3::brokerOutput::sendToOutputTopics ( const std::string & message )

protected

Sends the provided message to each of the output topics.

Parameters

message - A string containing the message

void glass3::brokerOutput::setStationFileName ( const std::string & filename )

Sets the station file name.

Parameters

filename - A string containing the file name

bool glass3::brokerOutput::setup ( std::shared_ptr< const json::Object > config )

overridevirtual

brokerOutput configuration function

This function configures the brokerOutput class.

Parameters

config - A pointer to a json::Object containing to the configuration to use

Returns: returns true if successful.

Reimplemented from glass3::output::output.

The documentation for this class was generated from the following files:

glass-broker-app/brokerOutput/brokerOutput.h
glass-broker-app/brokerOutput/brokerOutput.cpp
