neic-glass3 Input class More...

#include <input.h>

Inheritance diagram for glass3::input::Input:

Collaboration diagram for glass3::input::Input:

Public Member Functions
	Input ()
	Input default constructor. More...

	Input (std::shared_ptr< const json::Object > config)
	Input advanced constructor. More...

	~Input ()
	Input destructor. More...

bool	setup (std::shared_ptr< const json::Object > config) override
	Input configuration function. More...

void	clear () override
	Input clear function. More...

std::shared_ptr< json::Object >	getInputData () override
	Input data getting function. More...

int	getInputDataCount () override
	Input data count function. More...

void	setInputDataMaxSize (int size)
	Function to set the maximum queue size. More...

int	getInputDataMaxSize ()
	Function to retrieve the maximum queue size. More...

Public Member Functions inherited from glass3::util::ThreadBaseClass
	ThreadBaseClass ()
	ThreadBaseClass constructor. More...

	ThreadBaseClass (std::string threadName, int sleepTimeMS=100, int numThreads=1, int checkInterval=300)
	An advanced constructor that sets up the ThreadBaseClass with a provided thread name, sleep between work time duration, number of threads, and statsus check interval. More...

	~ThreadBaseClass ()
	ThreadBaseClass destructor. More...

virtual bool	start ()
	work thread start function More...

virtual bool	stop ()
	work thread stop function More...

int	getNumThreads ()
	Retrieves the number of work threads. More...

void	setNumThreads (int numThreads)
	Sets the number of work threads. More...

void	setThreadHealth (bool health=true)
	Function to set thread health. More...

virtual bool	healthCheck ()
	work threads check function More...

void	setSleepTime (int sleepTimeMS)
	Sets the time to sleep between work() calls. More...

int	getSleepTime ()
	Retrieves the time to sleep between work() calls. More...

glass3::util::ThreadState	getWorkThreadsState ()
	Function to get the work threads state. More...

void	setHealthCheckInterval (int interval)
	Function to set work threads health check interval. More...

int	getHealthCheckInterval ()
	Function to retrieve the work threads health check interval. More...

bool	getTerminate ()
	Function to retrieve whether the thread should terminate. More...

const std::string &	getThreadName ()
	Function to retrieve the name of the work threads. More...

std::time_t	getAllLastHealthy (size_t *pThreadId)
	Function to retrieve the oldest time any of the work threads last updated their health status as healthy. More...

Public Member Functions inherited from glass3::util::BaseClass
	BaseClass ()
	BaseClass constructor. More...

virtual	~BaseClass ()
	BaseClass destructor. More...

const std::shared_ptr< const json::Object >	getConfig ()

bool	getSetup ()
	Retrieves the class member boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

const std::string &	getDefaultAgencyId ()
	Function to retrieve the name of the default agency id. More...

void	setDefaultAgencyId (const std::string &id)
	Function to set the name of the default agency id. More...

const std::string &	getDefaultAuthor ()
	Function to retrieve the name of the default author. More...

void	setDefaultAuthor (const std::string &author)
	Function to set the name of the default author. More...

Protected Member Functions
glass3::util::WorkState	work () override
	Input work function. More...

virtual std::shared_ptr< json::Object >	parse (std::string inputType, std::string inputMessage)
	parse line function More...

virtual std::string	fetchRawData (std::string *pOutType)=0
	get Input data string and type More...

Protected Member Functions inherited from glass3::util::ThreadBaseClass
void	setWorkThreadsState (glass3::util::ThreadState state)
	Function to set threads state. More...

void	workLoop ()
	ThreadBaseClass work loop function. More...

void	setLastHealthy (std::time_t now)
	Function to set the last time the work thread was healthy. More...

Additional Inherited Members
Protected Attributes inherited from glass3::util::ThreadBaseClass
std::vector< std::thread >	m_WorkThreads
	the std::vector that contains the work std::thread objects More...

std::map< std::thread::id, std::atomic< int > >	m_ThreadHealthMap
	A std::map containing the epoch times as std::atomic<double>> that each work thread was last marked as healthy, identified by the thread id. More...

Protected Attributes inherited from glass3::util::BaseClass
std::shared_ptr< const json::Object >	m_Config
	A shared pointer to the json::Object that holds the configuration. More...

std::atomic< bool >	m_bIsSetup
	the boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

std::string	m_DefaultAgencyID
	A std::string containing the default agency id to use in parsing if one is not provided. More...

std::string	m_DefaultAuthor
	A std::string containing the default author to use in parsing if one is not provided. More...

Detailed Description

neic-glass3 Input class

The neic-glass3 Input class is a thread class encapsulating the data Input logic for neic-glass3. The Input class handles reading Input data, parsing it, validating it, and queuing it for later use byglasscore via the Associator class. If the internal queue isfull, the class will pause reading Input data until space is available.

The input class generates detection format json messages as defined in https://github.com/usgs/earthquake-detection-formats/tree/master/format-docs that are then passed to the associator/glasscore via a queue.

The Input class is intended to be inherited from to define application specific input mechanisms (i.e. input from disk files).

Input inherits from the glass3::util::ThreadBaseClass class. Input implements the glass3::util::iInput interface.

Constructor & Destructor Documentation

glass3::input::Input::Input ( )

Input default constructor.

The default constructor for the Input class. Initializes members to default values.

glass3::input::Input::Input ( std::shared_ptr< const json::Object > config )

explicit

Input advanced constructor.

The advanced constructor for the Input class. This function calls setup to configure the class, initializing members to the configured values, and starts the work thread

Parameters

config - A json::Object shared_ptr to the configuration to use

glass3::input::Input::~Input ( )

Input destructor.

The destructor for the Input class. Stops the work thread

Member Function Documentation

void glass3::input::Input::clear ( )

overridevirtual

Input clear function.

The clear function for the Input class. Clears all configuration, clears and reallocates the message queue and cache

Reimplemented from glass3::util::BaseClass.

Reimplemented in glass3::fileInput, and glass3::brokerInput.

virtual std::string glass3::input::Input::fetchRawData ( std::string * pOutType )

protectedpure virtual

get Input data string and type

A pure virtual function that retrieves the next data message and type from an Input source

Parameters

pOutType - A pointer to a std::string used to pass out the type of the data

Returns: returns a std::string containing the Input data message

Implemented in glass3::fileInput, and glass3::brokerInput.

std::shared_ptr< json::Object > glass3::input::Input::getInputData ( )

overridevirtual

Input data getting function.

The function (from iinput) used to get Input data from the data queue.

Returns: Returns a pointer to a json::Object containing the data, or NULL if the Input queue is empty

Implements glass3::util::iInput.

int glass3::input::Input::getInputDataCount ( )

overridevirtual

Input data count function.

The function (from iInput) used to get the count of how much data is in the data queue.

Returns: Returns a postitve integer containing the count of data currently in the Input queue

Implements glass3::util::iInput.

int glass3::input::Input::getInputDataMaxSize ( )

Function to retrieve the maximum queue size.

This function retrieves the maximum allowable size of the Input data queue

Returns: Returns an integer value containing the maximum queue size

std::shared_ptr< json::Object > glass3::input::Input::parse	(	std::string	inputType,
		std::string	inputMessage
	)

protectedvirtual

parse line function

The function that parses an Input line, based on the given extension

Parameters

inputType - A std::string containing the type of data to parse

Returns: returns a shared pointer to a json::Object containing the parsed

Parameters

inputMessage - A std::string containing the input message line to parse

void glass3::input::Input::setInputDataMaxSize ( int size )

Function to set the maximum queue size.

This function sets the maximum allowable size of the Input data queue. Setting this value to -1 indicates that there is no maximum size to the Input queue

Parameters

size	= An integer value containing the maximum queue size

bool glass3::input::Input::setup ( std::shared_ptr< const json::Object > config )

overridevirtual

Input configuration function.

The this function configures the Input class, The setup() function can be called multiple times, in order to reload or update configuration information.

Parameters

config - A pointer to a json::Object containing to the configuration to use
