glass association class More...

#include <associator.h>

Inheritance diagram for glass3::process::Associator:

Collaboration diagram for glass3::process::Associator:

Public Member Functions
	Associator (glass3::util::iInput inputint, glass3::util::iOutput outputint)
	associator constructor More...

	~Associator ()
	associator destructor More...

bool	setup (std::shared_ptr< const json::Object > config) override
	Associator configuration function. More...

void	clear () override
	associator clear function More...

void	recieveGlassMessage (std::shared_ptr< json::Object > communication) override
	glasscore message receiver function More...

void	sendToAssociator (std::shared_ptr< json::Object > &message) override
	glasscore message sending function More...

bool	healthCheck () override
	associator heath check function More...

Public Member Functions inherited from glass3::util::ThreadBaseClass
	ThreadBaseClass ()
	ThreadBaseClass constructor. More...

	ThreadBaseClass (std::string threadName, int sleepTimeMS=100, int numThreads=1, int checkInterval=300)
	An advanced constructor that sets up the ThreadBaseClass with a provided thread name, sleep between work time duration, number of threads, and statsus check interval. More...

	~ThreadBaseClass ()
	ThreadBaseClass destructor. More...

virtual bool	start ()
	work thread start function More...

virtual bool	stop ()
	work thread stop function More...

int	getNumThreads ()
	Retrieves the number of work threads. More...

void	setNumThreads (int numThreads)
	Sets the number of work threads. More...

void	setThreadHealth (bool health=true)
	Function to set thread health. More...

void	setSleepTime (int sleepTimeMS)
	Sets the time to sleep between work() calls. More...

int	getSleepTime ()
	Retrieves the time to sleep between work() calls. More...

glass3::util::ThreadState	getWorkThreadsState ()
	Function to get the work threads state. More...

void	setHealthCheckInterval (int interval)
	Function to set work threads health check interval. More...

int	getHealthCheckInterval ()
	Function to retrieve the work threads health check interval. More...

bool	getTerminate ()
	Function to retrieve whether the thread should terminate. More...

const std::string &	getThreadName ()
	Function to retrieve the name of the work threads. More...

std::time_t	getAllLastHealthy (size_t *pThreadId)
	Function to retrieve the oldest time any of the work threads last updated their health status as healthy. More...

Public Member Functions inherited from glass3::util::BaseClass
	BaseClass ()
	BaseClass constructor. More...

virtual	~BaseClass ()
	BaseClass destructor. More...

const std::shared_ptr< const json::Object >	getConfig ()

bool	getSetup ()
	Retrieves the class member boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

const std::string &	getDefaultAgencyId ()
	Function to retrieve the name of the default agency id. More...

void	setDefaultAgencyId (const std::string &id)
	Function to set the name of the default agency id. More...

const std::string &	getDefaultAuthor ()
	Function to retrieve the name of the default author. More...

void	setDefaultAuthor (const std::string &author)
	Function to set the name of the default author. More...

Protected Member Functions
glass3::util::WorkState	work () override
	associator work function More...

Protected Member Functions inherited from glass3::util::ThreadBaseClass
void	setWorkThreadsState (glass3::util::ThreadState state)
	Function to set threads state. More...

void	workLoop ()
	ThreadBaseClass work loop function. More...

void	setLastHealthy (std::time_t now)
	Function to set the last time the work thread was healthy. More...

Additional Inherited Members
Protected Attributes inherited from glass3::util::ThreadBaseClass
std::vector< std::thread >	m_WorkThreads
	the std::vector that contains the work std::thread objects More...

std::map< std::thread::id, std::atomic< int > >	m_ThreadHealthMap
	A std::map containing the epoch times as std::atomic<double>> that each work thread was last marked as healthy, identified by the thread id. More...

Protected Attributes inherited from glass3::util::BaseClass
std::shared_ptr< const json::Object >	m_Config
	A shared pointer to the json::Object that holds the configuration. More...

std::atomic< bool >	m_bIsSetup
	the boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

std::string	m_DefaultAgencyID
	A std::string containing the default agency id to use in parsing if one is not provided. More...

std::string	m_DefaultAuthor
	A std::string containing the default author to use in parsing if one is not provided. More...

Detailed Description

glass association class

The glass association class is a thread class hosting the glass core association and nucleation engine. The associator class pulls input data from the input class, and sends it into glasscore. It also routes any results to the output class. The class also sends any configuration into glasscore.

associator inherits from the glass3::util::ThreadBaseClass class.

associator implements the glasscore::IGlassSend and glass3::util::iAssociator interfaces.

Constructor & Destructor Documentation

glass3::process::Associator::Associator	(	glass3::util::iInput *	inputint,
		glass3::util::iOutput *	outputint
	)

associator constructor

Parameterized constructor for the associator class, which: Initializes members to default values. Sets the interface pointers to other classes

Parameters

inputint	- A glass3::util::iinput pointer to the input class.
outputint	- A glass3::util::ioutput pointer to the output class.

glass3::process::Associator::~Associator ( )

associator destructor

The destructor for the associator class.

Member Function Documentation

void glass3::process::Associator::clear ( )

overridevirtual

associator clear function

The clear function for the associator class. Clears all configuration, clears and reallocates the message queue and glasscore instance

Reimplemented from glass3::util::BaseClass.

bool glass3::process::Associator::healthCheck ( )

overridevirtual

associator heath check function

Overrides ThreadBaseClass::healthCheck to add monitoring glasscore. Uses ThreadBaseClass::healthCheck to monitor worker thread

Returns: returns true if glasscore and worker thread are still running.

Reimplemented from glass3::util::ThreadBaseClass.

void glass3::process::Associator::recieveGlassMessage ( std::shared_ptr< json::Object > communication )

overridevirtual

glasscore message receiver function

The function (from IGlassSend) used to receive communication from the glasscore library.

Parameters

communication - A shared_ptr a to json::Object containing the message from glasscore.

Implements glasscore::IGlassSend.

void glass3::process::Associator::sendToAssociator ( std::shared_ptr< json::Object > & message )

overridevirtual

glasscore message sending function

The function (from iassociator) used to send communication to glasscore.

Parameters

message - A shared_ptr to a json::Object containing the message to send to the glasscore library.

Implements glass3::util::iAssociator.

bool glass3::process::Associator::setup ( std::shared_ptr< const json::Object > config )

overridevirtual

Associator configuration function.

The this function configures the Associator class i.e. configures glasscore. The setup() function can be called multiple times, in order to reload or update configuration information.

Parameters

config - A shared_ptr to a json::Object containing to the configuration to pass to glasscore.

Returns: returns true if successful.

Reimplemented from glass3::util::BaseClass.

glass3::util::WorkState glass3::process::Associator::work ( )

overrideprotectedvirtual

associator work function

The function (from threadclassbase) used to do work. For Associator, this includes sending configuration, messages, and input data to the glasscore library

Returns: returns true if work was successful, false otherwise.

Implements glass3::util::ThreadBaseClass.

The documentation for this class was generated from the following files:

process/include/associator.h
process/src/associator.cpp
