geographic coordinate conversion class More...

#include <geo.h>

Collaboration diagram for glass3::util::Geo:

Public Member Functions
	Geo ()
	CGeo constructor. More...

	Geo (double lat, double lon, double rad, double cartX, double cartY, double cartZ, double unitX, double unitY, double unitZ)
	CGeo alternate constructor. More...

	Geo (Geo *geo)
	CGeo copy constructor. More...

virtual	~Geo ()
	CGeo destructor. More...

void	initialize (double lat, double lon, double rad, double cartX, double cartY, double cartZ, double unitX, double unitY, double unitZ)
	CGeo init method. More...

virtual void	clone (Geo *geo)
	CGeo clone method. More...

void	clear ()
	CGeo clear function. More...

virtual void	setGeographic (double lat, double lon, double r)
	CGeo geographic coordinate set function. More...

virtual void	setGeocentric (double lat, double lon, double r)
	CGeo geocentric coordinate set function. More...

virtual void	getGeographic (double lat, double lon, double *r)
	CGeo geographic coordinate get function. More...

virtual void	getGeocentric (double lat, double lon, double *r)
	CGeo geographic coordinate get function. More...

virtual void	setCartesian (double x, double y, double z)
	CGeo Cartesian coordinate set function. More...

virtual double	delta (Geo *geo)
	Calculate the distance to a given CGeo object. More...

virtual double	azimuth (Geo *geo)
	Calculate the azimuth to a given CGeo object. More...

Public Attributes
double	m_dGeocentricLatitude
	the double value containing the geocentric latitude in degrees. More...

double	m_dGeocentricLongitude
	the double value containing the geocentric longitude in degrees. More...

double	m_dGeocentricRadius
	the double value containing the geocentric radius in kilometers. More...

double	m_dCartesianX
	the double value containing the Cartesian x coordinate. More...

double	m_dCartesianY
	the double value containing the Cartesian y coordinate. More...

double	m_dCartesianZ
	the double value containing the Cartesian z coordinate. More...

double	m_dUnitVectorX
	the double value containing the x unit vector used in delta calculations More...

double	m_dUnitVectorY
	the double value containing the y unit vector used in delta calculations More...

double	m_dUnitVectorZ
	the double value containing the z unit vector used in delta calculations More...

Static Public Attributes
static constexpr double	k_EarthRadiusKm = 6371.0
	Average earth radius in kilometers. More...

static constexpr double	k_DegreesToKm = 111.19
	Degrees to Kilometers conversion factor based on 6371 as the average radius. More...

static constexpr double	k_KmToDegrees = 0.00899
	Kilometers to Degrees conversion factor based on 6371 as the average radius. More...

static constexpr double	k_MaximumLatitude = 90.0
	Maximum possible latitude value. More...

static constexpr double	k_MinimumLatitude = -90.0
	Minimum possible latitude value. More...

static constexpr double	k_MaximumLongitude = 180.0
	Maximum possible longitude value. More...

static constexpr double	k_MinimumLongitude = -180.0
	Minimum possible longitude value. More...

static constexpr double	k_LongitudeWrap = 360.0
	Longitude wrap factor. More...

static constexpr double	k_GeographicToGeocentric = 0.993277
	Latitude geographic to geocentric conversion factor. More...

static constexpr double	k_dMetersToKm = 0.001
	The factor used to convert meters to kilometers. More...

static constexpr double	k_dElevationToDepth = -1.0
	The factor used to elevation to depth. More...

Detailed Description

geographic coordinate conversion class

The CGeo class is a class that encapsulates the logic necessary to convert geographic, geocentric, and Cartesian coordinates to geographic and geocentric coordinates. The class also computes the distance and azimuth between coordinates, and intersections between geographic (or geocentric) spheres.

Constructor & Destructor Documentation

glass3::util::Geo::Geo ( )

CGeo constructor.

The constructor for the CGeo class.

glass3::util::Geo::Geo	(	double	lat,
		double	lon,
		double	rad,
		double	cartX,
		double	cartY,
		double	cartZ,
		double	unitX,
		double	unitY,
		double	unitZ
	)

CGeo alternate constructor.

The atlernate constructor for the CGeo class.

Parameters

lat	- The geocentric latitude in degrees
lon	- The geocentric longitude in degrees
rad	- The geocentric radius in kilometers
cartX	- The Cartesian x coordinate.
cartY	- The Cartesian y coordinate.
cartZ	- The Cartesian z coordinate.
unitX	- The x unit vector
unitY	- The y unit vector
unitZ	- The z unit vector

glass3::util::Geo::Geo ( Geo * geo )

explicit

CGeo copy constructor.

The copy constructor for the CGeo class.

Parameters

geo	- A pointer to a CGeo object to copy from

glass3::util::Geo::~Geo ( )

virtual

CGeo destructor.

The destructor for the CGeo class.

Member Function Documentation

double glass3::util::Geo::azimuth ( Geo * geo )

virtual

Calculate the azimuth to a given CGeo object.

Computes the azimuth in radians from this object to a given CGeo object

Parameters

geo	- A pointer to the CGeo object to calculate azimuth to

Returns: Returns the azimuth in radians between the two CGeo objects.

void glass3::util::Geo::clear ( )

CGeo clear function.

void glass3::util::Geo::clone ( Geo * geo )

virtual

CGeo clone method.

The clone method for the CGeo class.

Parameters

geo	- A pointer to a CGeo object to clone from

double glass3::util::Geo::delta ( Geo * geo )

virtual

Calculate the distance to a given CGeo object.

Computes the distance in radians from this object to a given CGeo object

Parameters

geo	- A pointer to the CGeo object to calculate distance to

Returns: Returns the distance in radians between the two CGeo objects.

void glass3::util::Geo::getGeocentric	(	double *	lat,
		double *	lon,
		double *	r
	)

virtual

CGeo geographic coordinate get function.

Gets the current geographic coordinates from CGeo. NOTE: Does not appear to be called by glassutil or glasscore!

Parameters

lat	- A pointer to the geographic latitude variable to populate in degrees
lon	- A pointer to the geographic longitude variable to populate in degrees
r	- A pointer to the geographic radius variable to populate in kilometers

void glass3::util::Geo::getGeographic	(	double *	lat,
		double *	lon,
		double *	r
	)

virtual

CGeo geographic coordinate get function.

Gets the current geographic coordinates from CGeo

Parameters

lat	- A pointer to the geographic latitude variable to populate in degrees
lon	- A pointer to the geographic longitude variable to populate in degrees
r	- A pointer to the geographic radius variable to populate in kilometers

void glass3::util::Geo::initialize	(	double	lat,
		double	lon,
		double	rad,
		double	cartX,
		double	cartY,
		double	cartZ,
		double	unitX,
		double	unitY,
		double	unitZ
	)

CGeo init method.

The initialize method for the CGeo class.

Parameters

lat	- The geocentric latitude in degrees
lon	- The geocentric longitude in degrees
rad	- The geocentric radius in kilometers
cartX	- The Cartesian x coordinate.
cartY	- The Cartesian y coordinate.
cartZ	- The Cartesian z coordinate.
unitX	- The x unit vector
unitY	- The y unit vector
unitZ	- The z unit vector

void glass3::util::Geo::setCartesian	(	double	x,
		double	y,
		double	z
	)

virtual

CGeo Cartesian coordinate set function.

Sets CGeo to the provided Cartesian coordinates. Computes the geocentric coordinates and unit vectors. NOTE: Does not appear to be called by glassutil or glasscore!

Parameters

x	- The Cartesian x coordinate
y	- The Cartesian y coordinate
z	- The Cartesian z coordinate

void glass3::util::Geo::setGeocentric	(	double	lat,
		double	lon,
		double	r
	)

virtual

CGeo geocentric coordinate set function.

Sets CGeo to the provided geocentric coordinates. Computes the Cartesian coordinates and unit vectors.

Parameters

lat	- The geocentric latitude in degrees
lon	- The geocentric longitude in degrees
r	- The geocentric radius in kilometers

void glass3::util::Geo::setGeographic	(	double	lat,
		double	lon,
		double	r
	)

virtual

CGeo geographic coordinate set function.

Converts geographic coordinates into geocentric coordinates and sets CGeo to those geocentric coordinates. Computes the Cartesian coordinates and unit vectors.

Parameters

lat	- The geographic latitude in degrees
lon	- The geographic longitude in degrees
r	- The geographic radius in kilometers

Member Data Documentation

constexpr double glass3::util::Geo::k_DegreesToKm = 111.19

static

Degrees to Kilometers conversion factor based on 6371 as the average radius.

constexpr double glass3::util::Geo::k_dElevationToDepth = -1.0

static

The factor used to elevation to depth.

constexpr double glass3::util::Geo::k_dMetersToKm = 0.001

static

The factor used to convert meters to kilometers.

constexpr double glass3::util::Geo::k_EarthRadiusKm = 6371.0

static

Average earth radius in kilometers.

constexpr double glass3::util::Geo::k_GeographicToGeocentric = 0.993277

static

Latitude geographic to geocentric conversion factor.

constexpr double glass3::util::Geo::k_KmToDegrees = 0.00899

static

Kilometers to Degrees conversion factor based on 6371 as the average radius.

constexpr double glass3::util::Geo::k_LongitudeWrap = 360.0

static

Longitude wrap factor.

constexpr double glass3::util::Geo::k_MaximumLatitude = 90.0

static

Maximum possible latitude value.

constexpr double glass3::util::Geo::k_MaximumLongitude = 180.0

static

Maximum possible longitude value.

constexpr double glass3::util::Geo::k_MinimumLatitude = -90.0

static

Minimum possible latitude value.

constexpr double glass3::util::Geo::k_MinimumLongitude = -180.0

static

Minimum possible longitude value.

double glass3::util::Geo::m_dCartesianX

the double value containing the Cartesian x coordinate.

double glass3::util::Geo::m_dCartesianY

the double value containing the Cartesian y coordinate.

double glass3::util::Geo::m_dCartesianZ

the double value containing the Cartesian z coordinate.

double glass3::util::Geo::m_dGeocentricLatitude

the double value containing the geocentric latitude in degrees.

double glass3::util::Geo::m_dGeocentricLongitude

the double value containing the geocentric longitude in degrees.

double glass3::util::Geo::m_dGeocentricRadius

the double value containing the geocentric radius in kilometers.

double glass3::util::Geo::m_dUnitVectorX

the double value containing the x unit vector used in delta calculations

double glass3::util::Geo::m_dUnitVectorY

the double value containing the y unit vector used in delta calculations

double glass3::util::Geo::m_dUnitVectorZ

the double value containing the z unit vector used in delta calculations

The documentation for this class was generated from the following files:

util/include/geo.h
util/src/geo.cpp
