glass3::util::Taper Class Reference

glassutil taper class More...

#include <taper.h>

Collaboration diagram for glass3::util::Taper:

Public Member Functions
	Taper ()
	Taper constructor. More...
	Taper (double x1, double x2, double x3, double x4)
	Taper constructor. More...
	Taper (const Taper &taper)
	Taper copy constructor. More...
	~Taper ()
	Taper destructor. More...
double	calculateValue (double x)
	Calculate the value of the function Calculate the value of the function for a given value. More...

Public Attributes
double	m_dX1
	A double value representing the start point of the averaging function and cosine ramp up. More...
double	m_dX2
	A double value representing the end of the cosine ramp up. More...
double	m_dX3
	A double value representing the start of the cosine ramp down. More...
double	m_dX4
	A double value representing the end point of the averaging function and cosine ramp down. More...

Detailed Description

glassutil taper class

The Taper class represents a simple function used for averaging over an interval. It uses a cosine based ramp up and ramp down at both ends for stability.

Constructor & Destructor Documentation

glass3::util::Taper::Taper

(

)

Taper constructor.

The constructor for the Taper class. Initializes members to default values.

glass3::util::Taper::Taper	(	double	x1,
		double	x2,
		double	x3,
		double	x4
	)

Taper constructor.

The constructor for the Taper class. Initializes members to provided values.

Parameters

x1	- A double value representing the start point of the averaging function
x2	- A double value representing the end of the cosine ramp up
x3	- A double value representing the start of the cosine ramp down
x4	- A double value representing the end point of the averaging function

glass3::util::Taper::Taper

(

const Taper &

taper

)

Taper copy constructor.

The copy constructor for the Taper class.

glass3::util::Taper::~Taper

(

)

Taper destructor.

The destructor for the Taper class.

Member Function Documentation

double glass3::util::Taper::calculateValue

(

double

x

)

Calculate the value of the function Calculate the value of the function for a given value.

Values less than dX1 evaluate to 0.0. Between dX1 and dX2 the value ramps up to 1.0 with a cosine taper, then is constant at 1.0 from dX2 to dX3 whence it ramps back down to 0.0 again with a cosine taper in reverse. Values greater than dX4 evaluate to 0.0.

Parameters

x	- A double value to calculate the taper value from.

Returns

Returns a double value containing the calculated taper value.

Member Data Documentation

double glass3::util::Taper::m_dX1

A double value representing the start point of the averaging function and cosine ramp up.

double glass3::util::Taper::m_dX2

A double value representing the end of the cosine ramp up.

double glass3::util::Taper::m_dX3

A double value representing the start of the cosine ramp down.

double glass3::util::Taper::m_dX4

A double value representing the end point of the averaging function and cosine ramp down.

---

The documentation for this class was generated from the following files:

• util/include/taper.h
• util/src/taper.cpp
