glass3::outputTopic Class Reference

glass3 output topic class More...

#include <outputTopic.h>

Collaboration diagram for glass3::outputTopic:

Public Member Functions
	outputTopic (hazdevbroker::Producer *producer)
	outputTopic constructor More...
	~outputTopic ()
	outputTopic destructor More...
bool	setup (const json::Value &config)
	outputTopic configuration function More...
void	clear ()
	outputTopic clear function More...
bool	isInBounds (double lat, double lon)
	outputTopic bounds check function More...
void	send (const std::string &message)
	outputTopic send function The function sends the provided message using the producer pointer and the configured topic. More...
void	heartbeat ()
	outputTopic heartbeat function The function sends generates a heartbeat using the producer pointer and the configured topic. Note that the producer takes care of deciding whether it has been long enough to generate a heartbeat More...

Protected Attributes
double	m_dTopLatitude
	the top of the bounds rectangle in degrees of latitude. More...
double	m_dBottomLatitude
	the bottom of the bounds rectangle in degrees of latitude. More...
double	m_dLeftLongitude
	the left side of the bounds rectangle in degrees of longitude. More...
double	m_dRightLongitude
	the right side of the bounds rectangle in degrees of longitude. More...
std::string	m_sTopicName
	the std::string containing the topic name More...

Detailed Description

glass3 output topic class

The glass3 output topic class is a class that encapsulates a broker output topic plus the bounds for which a message should be sent via that topic.

Constructor & Destructor Documentation

glass3::outputTopic::outputTopic ( hazdevbroker::Producer *  producer )

explicit

outputTopic constructor

The outputTopic for the brokerOutput class. Initializes members to default values, sets the hazdevbroker::Producer pointer.

Parameters

producer

- A pointer to a hazdevbroker::Producer to use for the topic.

glass3::outputTopic::~outputTopic

(

)

outputTopic destructor

The destructor for the outputTopic class.

Member Function Documentation

void glass3::outputTopic::clear

(

)

outputTopic clear function

The clear function for the outputTopic class. Clears all configuration

void glass3::outputTopic::heartbeat

(

)

outputTopic heartbeat function The function sends generates a heartbeat using the producer pointer and the configured topic. Note that the producer takes care of deciding whether it has been long enough to generate a heartbeat

bool glass3::outputTopic::isInBounds	(	double	lat,
		double	lon
	)

outputTopic bounds check function

This function checks to see if the provided coordinates are within the bounds for this outputTopic.

Parameters

lat	- a double value containing the latitude to check in degrees
lon	- a double value containing the longitude to check in degrees

Returns

Returns true if the provided coordinates are within the bounds, false otherwise

void glass3::outputTopic::send

(

const std::string &

message

)

outputTopic send function The function sends the provided message using the producer pointer and the configured topic.

Parameters

message

- A string containing the message

bool glass3::outputTopic::setup

(

const json::Value &

config

)

outputTopic configuration function

The this function configures the outputTopic class

Parameters

config

- A pointer to a json::Value containing to the configuration to use

Returns

returns true if successful.

Member Data Documentation

double glass3::outputTopic::m_dBottomLatitude

protected

the bottom of the bounds rectangle in degrees of latitude.

double glass3::outputTopic::m_dLeftLongitude

protected

the left side of the bounds rectangle in degrees of longitude.

double glass3::outputTopic::m_dRightLongitude

protected

the right side of the bounds rectangle in degrees of longitude.

double glass3::outputTopic::m_dTopLatitude

protected

the top of the bounds rectangle in degrees of latitude.

std::string glass3::outputTopic::m_sTopicName

protected

the std::string containing the topic name

---

The documentation for this class was generated from the following files:

• glass-broker-app/brokerOutput/outputTopic.h
• glass-broker-app/brokerOutput/outputTopic.cpp
