glasscore site list class More...

#include <SiteList.h>

Inheritance diagram for glasscore::CSiteList:

Collaboration diagram for glasscore::CSiteList:

Public Member Functions
	CSiteList (int numThreads=1, int sleepTime=100, int checkInterval=60)
	CSiteList constructor. More...

	~CSiteList ()
	CSiteList destructor. More...

void	clear () override
	CSiteList clear function. More...

bool	receiveExternalMessage (std::shared_ptr< json::Object > com)
	CSiteList communication receiving function. More...

bool	addSiteFromJSON (std::shared_ptr< json::Object > com)
	CSiteList add/update site function. More...

bool	addListOfSitesFromJSON (std::shared_ptr< json::Object > com)
	CSiteList add list of sites function. More...

bool	addSite (std::shared_ptr< CSite > site)
	CSiteList add/update site function. More...

int	size () const
	CSiteList Site count function. More...

std::shared_ptr< CSite >	getSite (std::string scnl)
	Get site by scnl. More...

std::shared_ptr< CSite >	getSite (std::string site, std::string comp, std::string net, std::string loc)
	Get site by station, component, network, and location. More...

std::vector< std::shared_ptr< CSite > >	getListOfSites ()
	Get current list of sites. More...

std::shared_ptr< json::Object >	generateSiteListMessage (bool send=true)
	Generate SiteList message. More...

int	getMaxHoursWithoutPicking () const
	Get the maximum hours without picking before a site is declared nonresponsive and unused, a -1 disables this metric. More...

void	setMaxHoursWithoutPicking (int hoursWithoutPicking)
	Set the maximum hours without picking before a site is declared nonresponsive and unused, a -1 disables this metric. More...

int	getHoursBeforeLookingUp () const
	Get the maximum hours between requesting site information from outside glasscore, a -1 disables this process. More...

void	setHoursBeforeLookingUp (int hoursBeforeLookingUp)
	Set the maximum hours between requesting site information from outside glasscore, a -1 disables this process. If enabled, glass will always re-request the coordinates and properties of this station every hoursBeforeLookingUp hours, regardless if the site is currently known. More...

int	getMaxPicksPerHour () const
	Get the maximum picks per hour before a site is declared too noisy to use, a -1 disables this metric. More...

void	setMaxPicksPerHour (int maxPicksPerHour)
	Set the maximum picks per hour before a site is declared too noisy to use, a -1 disables this metric. More...

int	getLastUpdated () const
	Get last time in epoch seconds the site list was modified. More...

glass3::util::WorkState	work () override
	SiteList work function. More...

Public Member Functions inherited from glass3::util::ThreadBaseClass
	ThreadBaseClass ()
	ThreadBaseClass constructor. More...

	ThreadBaseClass (std::string threadName, int sleepTimeMS=100, int numThreads=1, int checkInterval=300)
	An advanced constructor that sets up the ThreadBaseClass with a provided thread name, sleep between work time duration, number of threads, and statsus check interval. More...

	~ThreadBaseClass ()
	ThreadBaseClass destructor. More...

virtual bool	start ()
	work thread start function More...

virtual bool	stop ()
	work thread stop function More...

int	getNumThreads ()
	Retrieves the number of work threads. More...

void	setNumThreads (int numThreads)
	Sets the number of work threads. More...

void	setThreadHealth (bool health=true)
	Function to set thread health. More...

virtual bool	healthCheck ()
	work threads check function More...

void	setSleepTime (int sleepTimeMS)
	Sets the time to sleep between work() calls. More...

int	getSleepTime ()
	Retrieves the time to sleep between work() calls. More...

glass3::util::ThreadState	getWorkThreadsState ()
	Function to get the work threads state. More...

void	setHealthCheckInterval (int interval)
	Function to set work threads health check interval. More...

int	getHealthCheckInterval ()
	Function to retrieve the work threads health check interval. More...

bool	getTerminate ()
	Function to retrieve whether the thread should terminate. More...

const std::string &	getThreadName ()
	Function to retrieve the name of the work threads. More...

std::time_t	getAllLastHealthy (size_t *pThreadId)
	Function to retrieve the oldest time any of the work threads last updated their health status as healthy. More...

Public Member Functions inherited from glass3::util::BaseClass
	BaseClass ()
	BaseClass constructor. More...

virtual	~BaseClass ()
	BaseClass destructor. More...

virtual bool	setup (std::shared_ptr< const json::Object > config)
	BaseClass configuration function. More...

const std::shared_ptr< const json::Object >	getConfig ()

bool	getSetup ()
	Retrieves the class member boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

const std::string &	getDefaultAgencyId ()
	Function to retrieve the name of the default agency id. More...

void	setDefaultAgencyId (const std::string &id)
	Function to set the name of the default agency id. More...

const std::string &	getDefaultAuthor ()
	Function to retrieve the name of the default author. More...

void	setDefaultAuthor (const std::string &author)
	Function to set the name of the default author. More...

Additional Inherited Members
Protected Member Functions inherited from glass3::util::ThreadBaseClass
void	setWorkThreadsState (glass3::util::ThreadState state)
	Function to set threads state. More...

void	workLoop ()
	ThreadBaseClass work loop function. More...

void	setLastHealthy (std::time_t now)
	Function to set the last time the work thread was healthy. More...

Protected Attributes inherited from glass3::util::ThreadBaseClass
std::vector< std::thread >	m_WorkThreads
	the std::vector that contains the work std::thread objects More...

std::map< std::thread::id, std::atomic< int > >	m_ThreadHealthMap
	A std::map containing the epoch times as std::atomic<double>> that each work thread was last marked as healthy, identified by the thread id. More...

Protected Attributes inherited from glass3::util::BaseClass
std::shared_ptr< const json::Object >	m_Config
	A shared pointer to the json::Object that holds the configuration. More...

std::atomic< bool >	m_bIsSetup
	the boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

std::string	m_DefaultAgencyID
	A std::string containing the default agency id to use in parsing if one is not provided. More...

std::string	m_DefaultAuthor
	A std::string containing the default author to use in parsing if one is not provided. More...

Detailed Description

glasscore site list class

The CSiteList class is the class that maintains a vector and :map of all the seismic stations used by glasscore.

CSiteList also maintains a std::vector mapping the string SCNL id to CSite objects

CSiteList contains functions to support new data input and clearing the list

CSiteList uses smart pointers (std::shared_ptr).

Constructor & Destructor Documentation

glasscore::CSiteList::CSiteList	(	int	numThreads = `1`,
		int	sleepTime = `100`,
		int	checkInterval = `60`
	)

explicit

CSiteList constructor.

The constructor for the CSiteList class. Initializes members to default values.

glasscore::CSiteList::~CSiteList ( )

CSiteList destructor.

The destructor for the CSiteList class.

Member Function Documentation

bool glasscore::CSiteList::addListOfSitesFromJSON ( std::shared_ptr< json::Object > com )

CSiteList add list of sites function.

The function used by CSiteList to add a whole list of sites

Parameters

com	- A pointer to a json::array containing the list of sites to add

Returns: Returns true if the site was complete and added by CSiteList, false otherwise

bool glasscore::CSiteList::addSite ( std::shared_ptr< CSite > site )

CSiteList add/update site function.

The function used by CSiteList to add a site to, or update a site in the vector and map.

Parameters

site	- A shared pointer pointer to the site to add or update.

Returns: Returns true if the site was complete and added by CSiteList, false otherwise

bool glasscore::CSiteList::addSiteFromJSON ( std::shared_ptr< json::Object > com )

CSiteList add/update site function.

The function used by CSiteList to add a site to, or update a site in the vector and map.

Parameters

com	- A pointer to a json::object containing the site to add or update.

Returns: Returns true if the site was complete and added by CSiteList, false otherwise

void glasscore::CSiteList::clear ( )

overridevirtual

CSiteList clear function.

Reimplemented from glass3::util::BaseClass.

std::shared_ptr< json::Object > glasscore::CSiteList::generateSiteListMessage ( bool send = true )

Generate SiteList message.

Generate a json object representing all thie sites in this SiteList in the "SiteList" format and optionally send a pointer to this object to CGlass (and out of glasscore) using the CGlass send function (pGlass->send)

Parameters

send	- A boolean flag indicating that in addition to generating the "SiteList" format message, the function should also send it. Defaults to true

Returns: Returns the generated json object in the "SiteList" format.

int glasscore::CSiteList::getHoursBeforeLookingUp ( ) const

Get the maximum hours between requesting site information from outside glasscore, a -1 disables this process.

Returns: Return an integer containing the maximum hours between requesting site information

int glasscore::CSiteList::getLastUpdated ( ) const

Get last time in epoch seconds the site list was modified.

Returns: Return the last time in epoch seconds the site list was modified

std::vector< std::shared_ptr< CSite > > glasscore::CSiteList::getListOfSites ( )

Get current list of sites.

Gets the current list of sites contained within this sitelist

Returns: Returns a vector of shared_ptr's to the CSite objects contained in this list

int glasscore::CSiteList::getMaxHoursWithoutPicking ( ) const

Get the maximum hours without picking before a site is declared nonresponsive and unused, a -1 disables this metric.

Returns: Return an integer containing the maximum hours without picking allowed

int glasscore::CSiteList::getMaxPicksPerHour ( ) const

Get the maximum picks per hour before a site is declared too noisy to use, a -1 disables this metric.

Returns: Return an integer containing the maximum picks per hour allowed

std::shared_ptr< CSite > glasscore::CSiteList::getSite ( std::string scnl )

Get site by scnl.

Gets a specific site using the given scnl id.

Parameters

scnl	- A std::string containing the scnl

Returns: Returns a shared_ptr to the CSite object containing the desired site.

std::shared_ptr< CSite > glasscore::CSiteList::getSite	(	std::string	site,
		std::string	comp,
		std::string	net,
		std::string	loc
	)

Get site by station, component, network, and location.

Gets a specific site using the given station, component, network, and location

Parameters

site	- A std::string containing the station
comp	- A std::string containing the component
net	- A std::string containing the network
loc	- A std::string containing the location

Returns: Returns a shared_ptr to the CSite object containing the desired site.

bool glasscore::CSiteList::receiveExternalMessage ( std::shared_ptr< json::Object > com )

CSiteList communication receiving function.

The function used by CSiteList to receive communication (such as configuration or input data), from outside the glasscore library, or it's parent CGlass.

Supports Site (add site data to list) SiteUse (enable or disable a site) and ClearGlass (clear all Site data) inputs.

Parameters

com	- A pointer to a json::object containing the communication.

Returns: Returns true if the communication was handled by CSiteList, false otherwise

void glasscore::CSiteList::setHoursBeforeLookingUp ( int hoursBeforeLookingUp )

Set the maximum hours between requesting site information from outside glasscore, a -1 disables this process. If enabled, glass will always re-request the coordinates and properties of this station every hoursBeforeLookingUp hours, regardless if the site is currently known.

Parameters

hoursBeforeLookingUp - an integer containing the maximum hours between requesting site information

void glasscore::CSiteList::setMaxHoursWithoutPicking ( int hoursWithoutPicking )

Set the maximum hours without picking before a site is declared nonresponsive and unused, a -1 disables this metric.

Parameters

hoursWithoutPicking - an integer containing the maximum hours without picking allowed

void glasscore::CSiteList::setMaxPicksPerHour ( int maxPicksPerHour )

Set the maximum picks per hour before a site is declared too noisy to use, a -1 disables this metric.

Parameters

maxPicksPerHour - an integer containing the maximum picks per hour allowed

int glasscore::CSiteList::size ( ) const

CSiteList Site count function.

Returns: Returns an integer variable containing the number of sites in CSiteList

glass3::util::WorkState glasscore::CSiteList::work ( )

overridevirtual

SiteList work function.

checks sites

Returns: returns glass3::util::WorkState::OK if work was successful, glass3::util::WorkState::Error if not.

Implements glass3::util::ThreadBaseClass.

The documentation for this class was generated from the following files:

glasscore/glasslib/include/SiteList.h
glasscore/glasslib/src/SiteList.cpp

Public Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation
