glasscore detection web class More...

#include <Web.h>

Inheritance diagram for glasscore::CWeb:

Collaboration diagram for glasscore::CWeb:

Public Member Functions
	CWeb (int numThreads=0, int sleepTime=100, int checkInterval=300)
	CWeb constructor. More...

	CWeb (std::string name, double thresh, int numDetect, int numNucleate, int resolution, bool update, bool save, bool allowControllingWebs, std::shared_ptr< traveltime::CTravelTime > firstTrav, std::shared_ptr< traveltime::CTravelTime > secondTrav, int numThreads=0, int sleepTime=100, int checkInterval=300, double aziTaper=360.0, double maxDepth=800.0, double aSeismicThresh=-1.0, int numASeismicNucleate=-1)
	CWeb advanced constructor. More...

	~CWeb ()
	CWeb destructor. More...

void	clear () override
	CWeb clear function. More...

bool	receiveExternalMessage (std::shared_ptr< json::Object > com)
	CWeb communication recieveing function. More...

bool	initialize (std::string name, double thresh, int numDetect, int numNucleate, int resolution, bool update, bool save, bool allowControllingWebs, std::shared_ptr< traveltime::CTravelTime > firstTrav, std::shared_ptr< traveltime::CTravelTime > secondTrav, double aziTaper=360.0, double maxDepth=800.0, double aSeismicThresh=-1.0, int numASeismicNucleate=-1)
	CWeb initialization function. More...

bool	generateLocalGrid (std::shared_ptr< json::Object > gridConfiguration)
	Generate a local detection grid. More...

bool	generateExplicitGrid (std::shared_ptr< json::Object > gridConfiguration)
	Generate a detection grid with explicit nodes. More...

bool	generateGlobalGrid (std::shared_ptr< json::Object > gridConfiguration)
	Generate a global detection grid. More...

bool	loadGridConfiguration (std::shared_ptr< json::Object > gridConfiguration)
	Load the common grid configuration. More...

bool	loadTravelTimes (json::Object *gridConfiguration)
	Load the travel times for this web. More...

bool	loadFilters (std::shared_ptr< json::Object > gridConfiguration)
	Load web filters. More...

bool	loadWebSiteList ()
	Load web site list. More...

void	sortSiteListForNode (double lat, double lon, double depth)
	Sort site list. More...

bool	addSiteToSiteList (std::shared_ptr< CSite > site)
	Add site to this web's sitelist This function adds the given site to the site list local to this web. More...

bool	removeSiteFromSiteList (std::shared_ptr< CSite > site)
	Remove site from this web's sitelist This function Removes the given site to the site list local to this web. More...

std::shared_ptr< CNode >	generateNode (double lat, double lon, double z, double resol)
	Create new node. More...

bool	addNode (std::shared_ptr< CNode > node)
	Add node to list. More...

std::shared_ptr< CNode >	generateNodeSites (std::shared_ptr< CNode > node)
	Create list of sites for node. More...

void	addSite (std::shared_ptr< CSite > site)
	Add site to this web This function adds the given site to the list of nodes linked to this web and restructure node site lists. More...

void	removeSite (std::shared_ptr< CSite > site)
	Remove site from this web This function removes the given site to the list of nodes linked to this web and restructure node site lists. More...

bool	nodesHaveSite (std::shared_ptr< CSite > site)
	Check if the nodes in this web has a site This function checks to see if the given site is used by any of the nodes in this web, used by CWebList. More...

bool	isSiteAllowed (std::shared_ptr< CSite > site, bool checkEnabled=true)
	Check to see if site allowed This function checks to see if a given site is allowed in the web by checking the given site against the configured site filters. More...

void	addJob (std::function< void()> newjob)
	add a job More...

double	getAzimuthTaper () const
	Get the azimuth taper used for this web. More...

double	getMaxDepth () const
	Get the maximum depth used for this web. More...

const CSiteList *	getSiteList () const
	Get the CSiteList pointer used by this web for site lookups. More...

void	setSiteList (CSiteList *siteList)
	Set the CSiteList pointer used by this web for site lookups. More...

bool	getUpdate () const
	Gets a flag indicating whether this web supports updates. More...

bool	getSaveGrid () const
	Gets a flag indicating whether this web supports saving its nodes to an external file. More...

bool	getAllowControllingWebs () const
	Gets a boolean flag that stores whether this web will allow other (smaller) webs to override it's nucleation thresholds. More...

double	getNodeResolution () const
	Gets the node resolution of this web. More...

double	getNucleationStackThreshold () const
	Gets the nucleation minimum stack threshold used for this web. More...

int	getNumStationsPerNode () const
	Gets the number of stations to link to each node in this web. More...

int	getNucleationDataCountThreshold () const
	Gets the nucleation data minimum threshold used for this web. More...

const std::string &	getName () const
	Gets the name of this web. More...

const std::shared_ptr< traveltime::CTravelTime > &	getNucleationTravelTime1 () const
	Gets the primary nucleation travel time for this web. More...

const std::shared_ptr< traveltime::CTravelTime > &	getNucleationTravelTime2 () const
	Gets the secondary nucleation travel time for this web. More...

int	getNetworksFilterSize () const
	Get the number of network filters for this web. More...

int	getSitesFilterSize () const
	Get the number of site filters for this web. More...

bool	getUseOnlyTeleseismicStations () const
	Gets the flag indicating whether this web should only use sites flagged as UseForTeleseismic. More...

int	size () const
	Get the number of nodes in this web. More...

glass3::util::WorkState	work () override
	Web work function. More...

bool	getZoneStatsAseismic (double dLat, double dLon)
	zone stats aseismic retrieval function More...

double	getZoneStatsMaxDepth (double dLat, double dLon)
	zone stats max depth retrieval function More...

double	getASeismicNucleationStackThreshold () const
	Gets the aseismic nucleation minimum stack threshold used for this web. More...

int	getASeismicNucleationDataCountThreshold () const
	Gets the aseismic nucleation data (picks) minimum threshold used for this web. More...

double	isWithin (double dLat, double dLon)
	is coordinate within web function More...

Public Member Functions inherited from glass3::util::ThreadBaseClass
	ThreadBaseClass ()
	ThreadBaseClass constructor. More...

	ThreadBaseClass (std::string threadName, int sleepTimeMS=100, int numThreads=1, int checkInterval=300)
	An advanced constructor that sets up the ThreadBaseClass with a provided thread name, sleep between work time duration, number of threads, and statsus check interval. More...

	~ThreadBaseClass ()
	ThreadBaseClass destructor. More...

virtual bool	start ()
	work thread start function More...

virtual bool	stop ()
	work thread stop function More...

int	getNumThreads ()
	Retrieves the number of work threads. More...

void	setNumThreads (int numThreads)
	Sets the number of work threads. More...

void	setThreadHealth (bool health=true)
	Function to set thread health. More...

virtual bool	healthCheck ()
	work threads check function More...

void	setSleepTime (int sleepTimeMS)
	Sets the time to sleep between work() calls. More...

int	getSleepTime ()
	Retrieves the time to sleep between work() calls. More...

glass3::util::ThreadState	getWorkThreadsState ()
	Function to get the work threads state. More...

void	setHealthCheckInterval (int interval)
	Function to set work threads health check interval. More...

int	getHealthCheckInterval ()
	Function to retrieve the work threads health check interval. More...

bool	getTerminate ()
	Function to retrieve whether the thread should terminate. More...

const std::string &	getThreadName ()
	Function to retrieve the name of the work threads. More...

std::time_t	getAllLastHealthy (size_t *pThreadId)
	Function to retrieve the oldest time any of the work threads last updated their health status as healthy. More...

Public Member Functions inherited from glass3::util::BaseClass
	BaseClass ()
	BaseClass constructor. More...

virtual	~BaseClass ()
	BaseClass destructor. More...

virtual bool	setup (std::shared_ptr< const json::Object > config)
	BaseClass configuration function. More...

const std::shared_ptr< const json::Object >	getConfig ()

bool	getSetup ()
	Retrieves the class member boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

const std::string &	getDefaultAgencyId ()
	Function to retrieve the name of the default agency id. More...

void	setDefaultAgencyId (const std::string &id)
	Function to set the name of the default agency id. More...

const std::string &	getDefaultAuthor ()
	Function to retrieve the name of the default author. More...

void	setDefaultAuthor (const std::string &author)
	Function to set the name of the default author. More...

Additional Inherited Members
Protected Member Functions inherited from glass3::util::ThreadBaseClass
void	setWorkThreadsState (glass3::util::ThreadState state)
	Function to set threads state. More...

void	workLoop ()
	ThreadBaseClass work loop function. More...

void	setLastHealthy (std::time_t now)
	Function to set the last time the work thread was healthy. More...

Protected Attributes inherited from glass3::util::ThreadBaseClass
std::vector< std::thread >	m_WorkThreads
	the std::vector that contains the work std::thread objects More...

std::map< std::thread::id, std::atomic< int > >	m_ThreadHealthMap
	A std::map containing the epoch times as std::atomic<double>> that each work thread was last marked as healthy, identified by the thread id. More...

Protected Attributes inherited from glass3::util::BaseClass
std::shared_ptr< const json::Object >	m_Config
	A shared pointer to the json::Object that holds the configuration. More...

std::atomic< bool >	m_bIsSetup
	the boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

std::string	m_DefaultAgencyID
	A std::string containing the default agency id to use in parsing if one is not provided. More...

std::string	m_DefaultAuthor
	A std::string containing the default author to use in parsing if one is not provided. More...

Detailed Description

glasscore detection web class

The CWeb class represents a detection graph database. CWeb contains the list of all the detection nodes.

CWeb uses a background thread to handle live reconfiguration / updates of the web.

CWeb uses smart pointers (std::shared_ptr).

Constructor & Destructor Documentation

glasscore::CWeb::CWeb	(	int	numThreads = `0`,
		int	sleepTime = `100`,
		int	checkInterval = `300`
	)

explicit

CWeb constructor.

The constructor for the CWeb class.

Parameters

numThreads	- An integer containing the desired number of background threads to process web updates.
sleepTime	- An integer containing the amount of time to sleep in milliseconds between jobs. Default 10
checkInterval	- An integer containing the amount of time in seconds between status checks. -1 to disable status checks. Default 300.

glasscore::CWeb::CWeb	(	std::string	name,
		double	thresh,
		int	numDetect,
		int	numNucleate,
		int	resolution,
		bool	update,
		bool	save,
		bool	allowControllingWebs,
		std::shared_ptr< traveltime::CTravelTime >	firstTrav,
		std::shared_ptr< traveltime::CTravelTime >	secondTrav,
		int	numThreads = `0`,
		int	sleepTime = `100`,
		int	checkInterval = `300`,
		double	aziTaper = `360.0`,
		double	maxDepth = `800.0`,
		double	aSeismicThresh = `-1.0`,
		int	numASeismicNucleate = `-1`
	)

CWeb advanced constructor.

The advanced constructor for the CWeb class. Initializes members to provided values.

Parameters

name	- A std::string containing the name of the web.
thresh	- A double value containing this web's nucleation threshold.
numDetect	- An integer value containing the number of sites to link with each node in the web.
numNucleate	- An integer value containing the number of sites required for the web to nucleate an event.
resolution	- A double value containing the desired resolution for this web
update	- A boolean flag indicating whether this web is allowed to update
save	- A boolean flag indicating whether this web should save it's nodes to a file
allowControllingWebs	- A boolean flag indicating whether this web will allow other (smaller) webs to override it's nucleation thresholds
firstTrav	- A shared pointer to the first CTravelTime object to use for travel time lookups.
secondTrav	- A shared pointer to the second CTravelTime object to use for travel time lookups.
numThreads	- An integer containing the desired number of background threads to process web updates, if set to 0, glass will halt until the web update is completed. Default 0.
sleepTime	- An integer containing the amount of time to sleep in milliseconds between jobs. Default 10
checkInterval	- An integer containing the amount of time in seconds between status checks. -1 to disable status checks. Default 60.
aziTaper	= A double value containing the azimuth taper to be used, defaults to 360
maxDepth	= A double value containing the maximum allowable depth defaults to 800 km.
aSeismicThresh	= An optional double value containing this web's aseismic nucleation threshold, -1.0 to disable.
numASeismicNucleate	= An optional integer value containing the number of sites required for the web to nucleate an event at an aseismic node, -1 to disable

glasscore::CWeb::~CWeb ( )

CWeb destructor.

The destructor for the CWeb class.

Member Function Documentation

void glasscore::CWeb::addJob ( std::function< void()> newjob )

add a job

Adds a job to the queue of jobs to be run by the background thread

Parameters

newjob - A std::function<void()> bound to the function containing the job to run

bool glasscore::CWeb::addNode ( std::shared_ptr< CNode > node )

Add node to list.

This function adds a new node to the list of nodes

Parameters

node	- A std::shared_ptr to the node to add

Returns: Returns true if successful, false otherwise

void glasscore::CWeb::addSite ( std::shared_ptr< CSite > site )

Add site to this web This function adds the given site to the list of nodes linked to this web and restructure node site lists.

Parameters

site	- A shared_ptr to a CSite object containing the site to add

bool glasscore::CWeb::addSiteToSiteList ( std::shared_ptr< CSite > site )

Add site to this web's sitelist This function adds the given site to the site list local to this web.

Parameters

site	- A shared_ptr to a CSite object containing the site to add

Returns: Returns true if successful, false otherwise

void glasscore::CWeb::clear ( )

overridevirtual

CWeb clear function.

The clear function for the CWeb class.

Reimplemented from glass3::util::BaseClass.

bool glasscore::CWeb::generateExplicitGrid ( std::shared_ptr< json::Object > gridConfiguration )

Generate a detection grid with explicit nodes.

This function initializes this web to the provided configuration and generates a detection grid of explicitly defined nodes

Parameters

gridConfiguration - A pointer to a json::object containing desired node configuration

Returns: Returns true if successful, false if a grid was not created.

bool glasscore::CWeb::generateGlobalGrid ( std::shared_ptr< json::Object > gridConfiguration )

Generate a global detection grid.

This function initializes this web to the provided configuration and generates a global detection grid of nodes

Parameters

gridConfiguration - A pointer to a json::object containing desired node configuration

Returns: Returns true if successful, false if a grid was not created.

bool glasscore::CWeb::generateLocalGrid ( std::shared_ptr< json::Object > gridConfiguration )

Generate a local detection grid.

This function initializes this web to the provided configuration and generates a local detection grid of nodes

Parameters

gridConfiguration - A pointer to a json::object containing desired node grid configuration

Returns: Returns true if successful, false if a grid was not created.

std::shared_ptr< CNode > glasscore::CWeb::generateNode	(	double	lat,
		double	lon,
		double	z,
		double	resol
	)

Create new node.

This function creates a new node centered on the provided latitude, longitude, depth, and spatial resolution. The new node is linked to the N closest sites (stations) where N is defined by nDetect.

Parameters

lat	- A double variable containing the latitude to use
lon	- A double variable containing the longitude to use
z	- A double variable containing the depth to use
resol	- A double variable containing the spatial resolution to use

Returns: Returns a std::shared_ptr to the newly created node.

std::shared_ptr< CNode > glasscore::CWeb::generateNodeSites ( std::shared_ptr< CNode > node )

Create list of sites for node.

This function links a node to the N closest sites (stations) where N is defined by nDetect.

Parameters

node	- A std::shared_ptr to the node to link sites to

Returns: Returns a std::shared_ptr to the updated node.

bool glasscore::CWeb::getAllowControllingWebs ( ) const

Gets a boolean flag that stores whether this web will allow other (smaller) webs to override it's nucleation thresholds.

Returns: Returns a boolean flag indicating whether this web will allow other (smaller) webs to override it's nucleation thresholds

int glasscore::CWeb::getASeismicNucleationDataCountThreshold ( ) const

Gets the aseismic nucleation data (picks) minimum threshold used for this web.

Returns: Returns an integer value containing the aseismic nucleation data minimum threshold

double glasscore::CWeb::getASeismicNucleationStackThreshold ( ) const

Gets the aseismic nucleation minimum stack threshold used for this web.

Returns: Returns a double value containing the aseismic nucleation minimum stack threshold

double glasscore::CWeb::getAzimuthTaper ( ) const

Get the azimuth taper used for this web.

Returns: Returns a double value containing the taper to use

double glasscore::CWeb::getMaxDepth ( ) const

Get the maximum depth used for this web.

Returns: Returns a double value containing the maximum depth to use

const std::string & glasscore::CWeb::getName ( ) const

Gets the name of this web.

Returns: Returns a std::string containing the name of this web

int glasscore::CWeb::getNetworksFilterSize ( ) const

Get the number of network filters for this web.

Returns: Returns an integer containing the number of network filters

double glasscore::CWeb::getNodeResolution ( ) const

Gets the node resolution of this web.

Returns: Returns a double value containing the node resolution of this web in kilometers

int glasscore::CWeb::getNucleationDataCountThreshold ( ) const

Gets the nucleation data minimum threshold used for this web.

Returns: Returns an integer value containing the nucleation data minimum threshold

double glasscore::CWeb::getNucleationStackThreshold ( ) const

Gets the nucleation minimum stack threshold used for this web.

Returns: Returns a double value containing the nucleation minimum stack threshold

const std::shared_ptr< traveltime::CTravelTime > & glasscore::CWeb::getNucleationTravelTime1 ( ) const

Gets the primary nucleation travel time for this web.

Returns: Returns a shared_ptr to the CTravelTime containing the primary nucleation travel time

const std::shared_ptr< traveltime::CTravelTime > & glasscore::CWeb::getNucleationTravelTime2 ( ) const

Gets the secondary nucleation travel time for this web.

Returns: Returns a shared_ptr to the CTravelTime containing the secondary nucleation travel time

int glasscore::CWeb::getNumStationsPerNode ( ) const

Gets the number of stations to link to each node in this web.

Returns: Returns an integer value containing the number of stations to link to each node

bool glasscore::CWeb::getSaveGrid ( ) const

Gets a flag indicating whether this web supports saving its nodes to an external file.

Returns: Returns a boolean flag indicating whether this web supports saving it's nodes, true if it does, false otherwise

const CSiteList * glasscore::CWeb::getSiteList ( ) const

Get the CSiteList pointer used by this web for site lookups.

Returns: Return a pointer to the CSiteList class used by this web

int glasscore::CWeb::getSitesFilterSize ( ) const

Get the number of site filters for this web.

Returns: Returns an integer containing the number of site filters

bool glasscore::CWeb::getUpdate ( ) const

Gets a flag indicating whether this web supports updates.

Returns: Returns a boolean flag indicating whether this web supports updates, true if it does, false otherwise

bool glasscore::CWeb::getUseOnlyTeleseismicStations ( ) const

Gets the flag indicating whether this web should only use sites flagged as UseForTeleseismic.

Returns: Returns a boolean flag indicating hether this web should only use sites lagged as UseForTeleseismic

bool glasscore::CWeb::getZoneStatsAseismic	(	double	dLat,
		double	dLon
	)

zone stats aseismic retrieval function

This function gets whether zone stats says a given latitude and longitude is aseismic

Parameters

dLat	- A double containing the latitude to use
dLon	- A double containing the longitude to use

Returns: Returns true if aseismic, false otherwise

double glasscore::CWeb::getZoneStatsMaxDepth	(	double	dLat,
		double	dLon
	)

zone stats max depth retrieval function

This function gets the zone stats max depth for a given latitude and longitude from zonestats

Parameters

dLat	- A double containing the latitude to use
dLon	- A double containing the longitude to use

Returns: Returns a double value containing the zone stats depth if no zonestats, will return the web max depth

bool glasscore::CWeb::initialize	(	std::string	name,
		double	thresh,
		int	numDetect,
		int	numNucleate,
		int	resolution,
		bool	update,
		bool	save,
		bool	allowControllingWebs,
		std::shared_ptr< traveltime::CTravelTime >	firstTrav,
		std::shared_ptr< traveltime::CTravelTime >	secondTrav,
		double	aziTaper = `360.0`,
		double	maxDepth = `800.0`,
		double	aSeismicThresh = `-1.0`,
		int	numASeismicNucleate = `-1`
	)

CWeb initialization function.

Parameters

name	- A std::string containing the name of the web.
thresh	- A double value containing this web's nucleation threshold.
numDetect	- An integer value containing the number of sites to link with each node in the web.
numNucleate	- An integer value containing the number of sites required for the web to nucleate an event.
resolution	- A double value containing the desired resolution for this web
update	- A boolean flag indicating whether this web is allowed to update
save	- A boolean flag indicating whether this web should save it's nodes to a file
allowControllingWebs	- A boolean flag indicating whether this web will allow other (smaller) webs to override it's nucleation thresholds
firstTrav	- A shared pointer to the first CTravelTime object to use for travel time lookups.
secondTrav	- A shared pointer to the second CTravelTime object to use for travel time lookups.
aziTaper	= A double value containing the azimuth taper to be used, defaults to 360
maxDepth	= A double value containing the maximum allowable depth defaults to 800 km.
aSeismicThresh	= An optional double value containing this web's aseismic nucleation threshold, -1.0 to disable.
numASeismicNucleate	= An optional integer value containing the number of sitesrequired for the web to nucleate an event, -1 to disable

Returns: Returns true if successful, false otherwise

bool glasscore::CWeb::isSiteAllowed	(	std::shared_ptr< CSite >	site,
		bool	checkEnabled = `true`
	)

Check to see if site allowed This function checks to see if a given site is allowed in the web by checking the given site against the configured site filters.

Parameters

site	- A shared pointer to a CSite object containing the site to check
checkEnabled	- A bool indicating whether to check the site enabled and use flags, default true

Returns: returns true if it is allowed, false otherwise

double glasscore::CWeb::isWithin	(	double	dLat,
		double	dLon
	)

is coordinate within web function

This function checks to see if the provided coordinates are within the web.

Parameters

dLat	- A double containing the latitude to use
dLon	- A double containing the longitude to use

Returns: Returns a double value holding overall size of the web (lat deg * lon deg)

bool glasscore::CWeb::loadFilters ( std::shared_ptr< json::Object > gridConfiguration )

Load web filters.

This function loads the various filter lists used in selecting eligible sites from the provided cofiguration

Parameters

gridConfiguration - A pointer to a json::object containing the web configuration

Returns: Returns true if successful, false otherwise.

bool glasscore::CWeb::loadGridConfiguration ( std::shared_ptr< json::Object > gridConfiguration )

Load the common grid configuration.

This function initializes this web to the provided configuration

Parameters

gridConfiguration - A pointer to a json::object containing desired configuration

Returns: Returns true if successful, false otherwise.

bool glasscore::CWeb::loadTravelTimes ( json::Object * gridConfiguration )

Load the travel times for this web.

This function loads the travel times used by this web using the provided configuration

Parameters

gridConfiguration - A pointer to a json::object containing the web configuration

Returns: Returns true if successful, false otherwise.

bool glasscore::CWeb::loadWebSiteList ( )

Load web site list.

This function loads the list of eligible sites (stations) to be used by this web, filtering out unused/disabled sites and sites excluded by the site filters via isSiteAllowed(). This list is stored in vSite.

Returns: Always returns true

bool glasscore::CWeb::nodesHaveSite ( std::shared_ptr< CSite > site )

Check if the nodes in this web has a site This function checks to see if the given site is used by any of the nodes in this web, used by CWebList.

Parameters

site	- A shared pointer to a CSite object containing the site to check

bool glasscore::CWeb::receiveExternalMessage ( std::shared_ptr< json::Object > com )

CWeb communication recieveing function.

The function used by CWeb to recieve communication (such as configuration or input data), from outside the glasscore library, or it's parent CGlass.

Supports Global (genrate global grid) Shell (generate grid at single depth), Grid (generate local grid), Single (generate single node), GetWeb (generate output message detailing detection graph database) inputs.

Parameters

com	- A pointer to a json::object containing the communication.

Returns: Returns true if the communication was handled by CWeb, false otherwise

void glasscore::CWeb::removeSite ( std::shared_ptr< CSite > site )

Remove site from this web This function removes the given site to the list of nodes linked to this web and restructure node site lists.

Parameters

site	- A shared pointer to a CSite object containing the site to remove

bool glasscore::CWeb::removeSiteFromSiteList ( std::shared_ptr< CSite > site )

Remove site from this web's sitelist This function Removes the given site to the site list local to this web.

Parameters

site	- A shared_ptr to a CSite object containing the site to remove

Returns: Returns true if successful, false otherwise

void glasscore::CWeb::setSiteList ( CSiteList * siteList )

Set the CSiteList pointer used by this web for site lookups.

Parameters

siteList - a pointer to the CSiteList class used by this web

int glasscore::CWeb::size ( ) const

Get the number of nodes in this web.

Returns: Returns an integer value containing the number of nodes in this web

void glasscore::CWeb::sortSiteListForNode	(	double	lat,
		double	lon,
		double	depth
	)

Sort site list.

This function sorts a list of sites stored in vSite in increasing distance from the given location at 0 depth. The function also populates the distance between the given location and the site as part of the std::pair in vSite.

Parameters

lat	- A double variable containing the latitude to use in degrees
lon	- A double variable containing the longitude to use in degrees
depth	- A double variable containing the depth to use in km

glass3::util::WorkState glasscore::CWeb::work ( )

overridevirtual

Web work function.

Update a web in the background

Returns: returns glass3::util::WorkState::OK if work was successful, glass3::util::WorkState::Error if not.

Implements glass3::util::ThreadBaseClass.

The documentation for this class was generated from the following files:

glasscore/glasslib/include/Web.h
glasscore/glasslib/src/Web.cpp

Public Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation
