glasscore pick list class More...

#include <PickList.h>

Inheritance diagram for glasscore::CPickList:

Collaboration diagram for glasscore::CPickList:

Public Member Functions
	CPickList (int numThreads=1, int sleepTime=50, int checkInterval=300)
	CPickList constructor. More...

	~CPickList ()
	CPickList destructor. More...

void	clear () override
	CPickList clear function. More...

bool	receiveExternalMessage (std::shared_ptr< json::Object > com)
	CPickList communication receiving function. More...

bool	addPick (std::shared_ptr< json::Object > pick)
	CPickList add pick function. More...

std::shared_ptr< CPick >	getDuplicate (double newTPick, std::string newSCNL, double tDuration)
	Checks if the provided pick time is a duplicate. More...

bool	scavenge (std::shared_ptr< CHypo > hyp, double tWindow=CHypoList::k_nHypoSearchPastDurationForPick)
	Search for any associable picks that match hypo. More...

const CSiteList *	getSiteList () const
	Get the CSiteList pointer used by this pick list for site lookups. More...

void	setSiteList (CSiteList *siteList)
	Set the CSiteList pointer used by this pick list for site lookups. More...

int	getMaxAllowablePickCount () const
	Get the maximum allowed size of this pick list. More...

void	setMaxAllowablePickCount (int pickMax)
	Set the maximum allowed size of this pick list. More...

int	getCountOfTotalPicksProcessed () const
	Get the total number of picks processed by this list. More...

int	length () const
	Get the current number of picks contained in this list. More...

std::vector< std::weak_ptr< CPick > >	getPicks (double t1, double t2)
	Get a vector of picks that fall within a time window. More...

glass3::util::WorkState	work () override
	PickList work function. More...

Public Member Functions inherited from glass3::util::ThreadBaseClass
	ThreadBaseClass ()
	ThreadBaseClass constructor. More...

	ThreadBaseClass (std::string threadName, int sleepTimeMS=100, int numThreads=1, int checkInterval=300)
	An advanced constructor that sets up the ThreadBaseClass with a provided thread name, sleep between work time duration, number of threads, and statsus check interval. More...

	~ThreadBaseClass ()
	ThreadBaseClass destructor. More...

virtual bool	start ()
	work thread start function More...

virtual bool	stop ()
	work thread stop function More...

int	getNumThreads ()
	Retrieves the number of work threads. More...

void	setNumThreads (int numThreads)
	Sets the number of work threads. More...

void	setThreadHealth (bool health=true)
	Function to set thread health. More...

virtual bool	healthCheck ()
	work threads check function More...

void	setSleepTime (int sleepTimeMS)
	Sets the time to sleep between work() calls. More...

int	getSleepTime ()
	Retrieves the time to sleep between work() calls. More...

glass3::util::ThreadState	getWorkThreadsState ()
	Function to get the work threads state. More...

void	setHealthCheckInterval (int interval)
	Function to set work threads health check interval. More...

int	getHealthCheckInterval ()
	Function to retrieve the work threads health check interval. More...

bool	getTerminate ()
	Function to retrieve whether the thread should terminate. More...

const std::string &	getThreadName ()
	Function to retrieve the name of the work threads. More...

std::time_t	getAllLastHealthy (size_t *pThreadId)
	Function to retrieve the oldest time any of the work threads last updated their health status as healthy. More...

Public Member Functions inherited from glass3::util::BaseClass
	BaseClass ()
	BaseClass constructor. More...

virtual	~BaseClass ()
	BaseClass destructor. More...

virtual bool	setup (std::shared_ptr< const json::Object > config)
	BaseClass configuration function. More...

const std::shared_ptr< const json::Object >	getConfig ()

bool	getSetup ()
	Retrieves the class member boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

const std::string &	getDefaultAgencyId ()
	Function to retrieve the name of the default agency id. More...

void	setDefaultAgencyId (const std::string &id)
	Function to set the name of the default agency id. More...

const std::string &	getDefaultAuthor ()
	Function to retrieve the name of the default author. More...

void	setDefaultAuthor (const std::string &author)
	Function to set the name of the default author. More...

Protected Member Functions
void	updatePosition (std::shared_ptr< CPick > pick)
	A PickList function that updates the position of the given pick in the multiset. More...

void	eraseFromMultiset (std::shared_ptr< CPick > pick)
	A PickList function that removes the given pick from the multiset. More...

Protected Member Functions inherited from glass3::util::ThreadBaseClass
void	setWorkThreadsState (glass3::util::ThreadState state)
	Function to set threads state. More...

void	workLoop ()
	ThreadBaseClass work loop function. More...

void	setLastHealthy (std::time_t now)
	Function to set the last time the work thread was healthy. More...

Additional Inherited Members
Protected Attributes inherited from glass3::util::ThreadBaseClass
std::vector< std::thread >	m_WorkThreads
	the std::vector that contains the work std::thread objects More...

std::map< std::thread::id, std::atomic< int > >	m_ThreadHealthMap
	A std::map containing the epoch times as std::atomic<double>> that each work thread was last marked as healthy, identified by the thread id. More...

Protected Attributes inherited from glass3::util::BaseClass
std::shared_ptr< const json::Object >	m_Config
	A shared pointer to the json::Object that holds the configuration. More...

std::atomic< bool >	m_bIsSetup
	the boolean flag indicating whether the class has been setup, set to true if setup was successful. More...

std::string	m_DefaultAgencyID
	A std::string containing the default agency id to use in parsing if one is not provided. More...

std::string	m_DefaultAuthor
	A std::string containing the default author to use in parsing if one is not provided. More...

Detailed Description

glasscore pick list class

The CPickList class is the class that maintains a std::multiset of all the waveform arrival picks being considered by glasscore.

CPickList contains functions to support pick parsing, scavenging, and nucleation.

CPickList uses smart pointers (std::shared_ptr).

Constructor & Destructor Documentation

glasscore::CPickList::CPickList	(	int	numThreads = `1`,
		int	sleepTime = `50`,
		int	checkInterval = `300`
	)

explicit

CPickList constructor.

The constructor for the CPickList class.

Parameters

numThreads	- An integer containing the number of threads in the pool. Default 1
sleepTime	- An integer containing the amount of time to sleep in milliseconds between jobs. Default 50
checkInterval	- An integer containing the amount of time in seconds between status checks. -1 to disable status checks. Default 300.

glasscore::CPickList::~CPickList ( )

CPickList destructor.

The destructor for the CPickList class.

Member Function Documentation

bool glasscore::CPickList::addPick ( std::shared_ptr< json::Object > pick )

CPickList add pick function.

The function used by CPickList to add a pick to the multiset, if the new pick causes the number of picks in the multiset to exceed the configured maximum, remove the oldest pick from the multiset, as well as try to remove it from the shorter list of picks in CSite.

This function will generate a json formatted request for site (station) information if the pick is from an unknown site via the CSiteList getSite() function.

This function will first attempt to associate the pick with an existing hypocenter via calling the CHypoList::associate() function. If association is unsuccessful, the pick is nucleated using the CPick::Nucleate() function.

Parameters

pick	- A pointer to a json::object containing the pick.

Returns: Returns true if the pick was usable and added by CPickList, false otherwise

void glasscore::CPickList::clear ( )

overridevirtual

CPickList clear function.

Reimplemented from glass3::util::BaseClass.

void glasscore::CPickList::eraseFromMultiset ( std::shared_ptr< CPick > pick )

protected

A PickList function that removes the given pick from the multiset.

Parameters

pick	- A shared_ptr to the pick to be removed

int glasscore::CPickList::getCountOfTotalPicksProcessed ( ) const

Get the total number of picks processed by this list.

Returns: Return an integer containing the total number of picks processed by this list

std::shared_ptr< CPick > glasscore::CPickList::getDuplicate	(	double	newTPick,
		std::string	newSCNL,
		double	tDuration
	)

Checks if the provided pick time is a duplicate.

Compares the given pick time with the existing pick list times, in order to determine whether the given pick is a duplicate of an existing pick.

Parameters

newTPick	- A double containing the arrival time of the pick
newSCNL	- A std::string containing the scnl of the new pick
tDuration	- A double containing the allowable matching time window duration in seconds

Returns: Returns a std::shared_ptr<CPick> to the first existing pick if there is a duplicate, NULL otherwise

int glasscore::CPickList::getMaxAllowablePickCount ( ) const

Get the maximum allowed size of this pick list.

Returns: Return an integer containing the maximum allowed size of this pick list

std::vector< std::weak_ptr< CPick > > glasscore::CPickList::getPicks	(	double	t1,
		double	t2
	)

Get a vector of picks that fall within a time window.

Get a vector of picks that fall within the provided time window from t1 to t2

Parameters

t1	- A double value containing the beginning of the time window in Gregorian seconds
t2	- A double value containing the end of the time window in Gregorian seconds

Returns: Return a std::vector of std::weak_ptrs to the picks within the time window

const CSiteList * glasscore::CPickList::getSiteList ( ) const

Get the CSiteList pointer used by this pick list for site lookups.

Returns: Return a pointer to the CSiteList class used by this pick list

int glasscore::CPickList::length ( ) const

Get the current number of picks contained in this list.

Returns: Return an integer containing the current number of picks contained in this list

bool glasscore::CPickList::receiveExternalMessage ( std::shared_ptr< json::Object > com )

CPickList communication receiving function.

The function used by CPickList to receive communication (such as configuration or input data), from outside the glasscore library, or it's parent CGlass.

Supports Pick (add pick data to list) input.

Parameters

com	- A pointer to a json::object containing the communication.

Returns: Returns true if the communication was handled by CPickList, false otherwise

bool glasscore::CPickList::scavenge	(	std::shared_ptr< CHypo >	hyp,
		double	tWindow = `CHypoList::k_nHypoSearchPastDurationForPick`
	)

Search for any associable picks that match hypo.

Search through all picks within a provided number seconds from the origin time of the given hypocenter, adding any picks that meet association criteria to the given hypocenter.

Parameters

hyp	- A shared_ptr to a CHypo object containing the hypocenter to attempt to associate to.
tWindow	- A double value containing the window to search picks from origin time in seconds, defaults to 3600.0

Returns: Returns true if any picks were associated to the hypocenter, false otherwise.

void glasscore::CPickList::setMaxAllowablePickCount ( int pickMax )

Set the maximum allowed size of this pick list.

Parameters

pickMax - an integer containing the maximum allowed size of this pick list

void glasscore::CPickList::setSiteList ( CSiteList * siteList )

Set the CSiteList pointer used by this pick list for site lookups.

Parameters

siteList - a pointer to the CSiteList class used by this pick list

void glasscore::CPickList::updatePosition ( std::shared_ptr< CPick > pick )

protected

A PickList function that updates the position of the given pick in the multiset.

Parameters

pick	- A shared_ptr to the pick that needs a position update

glass3::util::WorkState glasscore::CPickList::work ( )

overridevirtual

PickList work function.

Attempts to associate and nuclate the next pick on the queue.

Returns: returns glass3::util::WorkState::OK if work was successful, glass3::util::WorkState::Error if not.

Implements glass3::util::ThreadBaseClass.

The documentation for this class was generated from the following files:

glasscore/glasslib/include/PickList.h
glasscore/glasslib/src/PickList.cpp
